Product Description:
- Long range 24-hours monitoring.
- Delicate and smooth images．
- Convenient for installation and application.
- 360 degree of Omni-directional Pan-Tilt
- Super-strong aluminum alloy with IP67
- Higher sensitivity
- Effective in all environments
- Lightweight design: weight ≤ 10kg
In summary, the PTZ Thermal Imaging Camera is a cutting-edge device that combines the benefits of thermal imaging technology with the versatility of a PTZ system. With its high resolution, advanced image processing capabilities, fast frame rate, and flexible PTZ functionality, this camera is ideal for applications that require precise thermal imaging, detailed monitoring, and efficient tracking of subjects. Whether used for security, surveillance, or other monitoring purposes, this thermal PTZ camera offers unmatched performance and reliability, making it a valuable tool for enhancing situational awareness and security measures.
Features:
- Support image scale, support LRF, support access to multiple sensors.
- Highly intelligent: support hotspots, smoke and fire alarms, temperature detection; support area intrusion detection; support vehicle, boat and human detection, classification and identification; support target tracking, screening and filtering; support AR intelligent information fusion linkage.
- Active defence: support for loud speaker + flashing lights to deter or deny criminals.
- Pitch: -90°to +90°, horizontal 360°continuous rotation, full coverage of 720° three-dimensional
Technical Parameters:
| Model |
HP-DMS10-2132 |
| Distance |
Day: 2000m
Night: 1000m
|
| Visible Camera |
1. Sensor type: back-illuminated ultra-low illumination starlight CMOS
2. Minimum illumination: color: 0.0005Lux @ black and white: 0.0001Lux @ 0Lux(IRON)
3. Lens:7mm～330mm, 47 times optical zoom, 16 times digital zoom.
4. Image processing: white balance, electronic shutter, frame accumulation, backlight compensation, glare suppression, 2D/3D digital noise reduction, electronic anti-shake, wide dynamic.
5. Day and night light: 0.4-0.75um visible light wide spectral window and 0.8-0.95um near-infrared spectral window day and night independent double light window, improve the signal-to-noise ratio of imaging light and stray light
6. Support electronic fog penetration and optical fog penetration
|
|
Laser
illuminator
|
1. Laser Homogenization: new infrared GHT-III HD flood light source, no scattered particles.
2. Laser angle: 2.1°～20°, DSS digital stepping lighting angle control technology, 0.1° precise follow-me control, automatic tracking or manual fine-tuning intelligent matching.
3. Laser distance: 1000m
4. Control modes: forced on, forced off, light sensitive automatic control in three modes, all can be set remotely
|
| Video audio |
1. Thermal camera resolution:support 1920×1080；1280×1024；1280×960；1024×768；1280×720；704×576；640×512；640×480；400×300；384×288；352×288；352×240
2. Visible camera resolution:2592×1520；2560×1440；1920×1080；1280×1024；1280×960；1024×768；1280×720；704×576；640×512；640×480；400×300；384×288；352×288；352×240
3. Video encoding: H.265/H.264/MJPEG,multi-stream support
4. Video code rate:32Kbps～16Mbps
5. Audio encoding:G.711A/ G.711U/G726
6. Image flip: left and right / up and down / diagonal
7. OSD settings: Support OSD display settings for channel name, time, gimbal orientation, field of view, focal length, and preset bit name settings
|
| Intelligent functions |
1. Intelligent analysis: support intrusion detection, boundary crossing detection, entering/leaving area detection, motion detection, wandering detection, people gathering, fast moving, target tracking, items left behind, items taken; people/vehicle target detection, face detection; and support 16 area settings; support intrusion detection people, vehicles filtering filtering function.
2. Automatic tracking: support single scene tracking/support multi-scene tracking/support panoramic tracking/support alarm linkage tracking.
3. Intelligent information fusion: support 512 AR intelligent information fusion, intelligent analysis of video identification information fusion, support orientation angle, field of view angle, focal length, magnification information fusion
4. Alarm management: support alarm capture and upload
|
| Enhanced Features |
1. Distance measurement: support passive distance measurement; support optional laser distance measurement.
2. Support sound and light alarm: internal integrated tweeter + flashing light, support alarm sound customization.
3. Support alarm linkage fire fighting device.
4. Camera diagnostic functions: support disconnection alarm, support IP conflict alarm, support illegal access alarm (illegal access times, lock time can be set), support SD card abnormal alarm (SD space is insufficient, SD card error, no SD card), video masking alarm, anti-sun damage (support threshold, masking time can be set).
5. Whole life management: health index record function, support working time, shutter count, working temperature, limit temperature, etc.; zoom lens and head each motor working cumulative time, etc.
6. Support disconnection renewal.
7. Power failure memory: support can restore the position before power failure, preset point state, cruise state, line sweep state.
8. Remote maintenance: with fault query, self-test, remote restart function; online upgrade, remote upgrade.
9. Key frame setting: support key frame interval 100 levels adjustable.
10. Configuration file: support configuration file import and export function.
11. Web access: support WEB full function configuration, remote online upgrade.
|
| Safety control |
1. Support illegal access alarm: the number of illegal access, lock time can be set.
- Support three levels of user rights management, administrator, operator and normal user.
- Security mode: authorized user name and password, support IP whitelist and blacklist, MAC whitelist and blacklist.
- User mis-login lockout
|
| PT |
1. Rotation speed: Horizontal: 0.01°/s～100°/s; Pitch: 0.01°/s～80°/s, support focal speed adaption.
2. Rotation angle: horizontal: 360° continuous rotation; pitch: -90°～+90°
3. Structure material: quasi-spherical design of micro-rotary, integrated 5-window multi-channel, fine cast high strength aluminium alloy material.
4. Window glass: infrared/visible high efficiency optical glass, clean film coating.
5. Surface coating: PTA triple anti-corrosion coating, anti-corrosion.
6. Wiper: support intelligent automatic wiper
7. Defrost: visible window defrost
8. Preset position cruise: 3000 preset positions, support 16 cruise routes, each can support 256 preset positions
9. Watch function: preset bit / pattern scan / cruise scan / vertical scan / frame scan / panorama scan / apple skin scan / horizontal fan sweep line scan
10. Support 3D frame selection zoom
11. Orientation information: support angle query/real-time return and positioning; support lens field of view return and positioning
12. Zero point correction: support northward zero point remote correction function
|
| Electrical interface |
1. Communication and control: 1 *RJ45 Ethernet port; 2* alarm inputs, 1 *alarm output; 1 *audio input input, 1 *RS485 interface.
2. Protocol: Support HTTP, HTTPS, FTP, SMTP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, DHCP network protocols; support ONVIF and GB28181 protocols.
3. Development interface: Support HP-SDK secondary development
|
| Power supply |
1. Working voltage: DC 9~36V, external AC220V or battery power adapter.
- Peak power consumption: ≤60W
|
| Environmental adaptation |
1. Working temperature: -40℃～60℃
- Working humidity: ≤95%
- Protection grade: IP67
- Anti-salt spray: no change in surface after 96 hours of continuous spraying at pH 6.5~7.2
- Electromagnetic compatibility: anti-surge 6KV, anti-static 8KV contact / 15KV air
|
| Volume weight |
1. Weight: ≤10kg
- Size: 312mm×200mm×296mm (L×W×H)
- Mounting: Front / side / wall / hanging / vehicle / tripod pro-rack
|
Company:
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
Hope-Wish solutions cover the border/coastal defense, anti UAV, intelligent transportation, forest fire prevention, environmental protection, individual photoelectric equipment (handheld, helmet, gun aiming), marine and other industries. The products developed by the Hope-Wish, with their excellent performance, reliable quality and thoughtful after-sales service has been widely praised by users all over the world.Applications:
The Hope-Wish PTZ Thermal Imaging Camera, model number HP-DMS, is a versatile and advanced surveillance tool that is developed in China. This cutting-edge device is specially designed for a wide range of applications and scenarios, making it a valuable asset in various industries.
One of the key product attributes of the Hope-Wish PTZ Thermal Imaging Camera is its ability to operate in extreme environmental conditions. With a storage temperature range of -30°C to +70°C, this thermal camera module is suitable for both indoor and outdoor use, providing reliable performance even in harsh climates.
The PTZ Thermal Imaging Camera by Hope-Wish is ideal for applications that require precise monitoring and detection capabilities. Its PTZ (Pan-Tilt-Zoom) functionality allows for flexible control and monitoring, making it perfect for surveillance in large areas such as industrial sites, public spaces, and critical infrastructure.
Equipped with advanced features such as motion detection and temperature alarm, the HP-DMS model offers enhanced security and real-time monitoring capabilities. The thermal sensor technology ensures accurate detection and visualization of heat signatures, making it a valuable tool for identifying potential threats or anomalies.
Whether used for security surveillance, perimeter monitoring, or search and rescue operations, the Hope-Wish PTZ Thermal Imaging Camera excels in providing clear and detailed thermal imaging. Its auto/manual focus capability allows users to adjust the focus as needed, ensuring optimal image quality in various scenarios.
In conclusion, the Hope-Wish PTZ Thermal Imaging Camera is a reliable and efficient solution for a wide range of applications and scenarios. Its advanced features, durable design, and high-performance thermal sensor make it a valuable asset for industries that require precise monitoring, detection, and surveillance capabilities.
Support and Services:
The PTZ Thermal Imaging Camera offers comprehensive Product Technical Support and Services to ensure optimal performance and user satisfaction. Our dedicated team of experts is available to assist with installation, troubleshooting, and any product-related queries.
Services include product training, software updates, and maintenance support to prolong the lifespan of your PTZ Thermal Imaging Camera. We strive to deliver prompt and reliable assistance to meet your technical needs and enhance your overall experience with our product.
Packing and Shipping:
Product Packaging and Shipping for PTZ Thermal Imaging Camera:
Our PTZ Thermal Imaging Camera is carefully packaged to ensure safe delivery to our customers. The product is securely placed in a sturdy cardboard box with protective cushioning materials to prevent any damage during transit.
Shipping Method:
We offer reliable shipping services to ensure timely delivery of your PTZ Thermal Imaging Camera. Depending on your location, we provide various shipping options including standard shipping and expedited shipping for faster delivery.
Order Processing:
Once your order is placed, our team processes it promptly to ensure quick dispatch of your PTZ Thermal Imaging Camera. You will receive a confirmation email with tracking details once your order has been shipped.
FAQ:
Q: What is the brand name of this PTZ Thermal Imaging Camera?
A: The brand name of this PTZ Thermal Imaging Camera is Hope-Wish.
Q: What is the model number of this PTZ Thermal Imaging Camera?
A: The model number of this PTZ Thermal Imaging Camera is HP-DMS.
Q: Where is this PTZ Thermal Imaging Camera manufactured?
A: This PTZ Thermal Imaging Camera is manufactured in China.
Q: What are the key features of this PTZ Thermal Imaging Camera?
A: Some key features of this PTZ Thermal Imaging Camera include high-resolution thermal imaging, pan-tilt-zoom functionality, long-range monitoring capabilities, and advanced thermal analytics.
Q: Is this PTZ Thermal Imaging Camera suitable for outdoor use?
A: Yes, this PTZ Thermal Imaging Camera is designed to be weatherproof and suitable for outdoor use, making it ideal for surveillance and security applications.
